Jabsco Hotshot HD4 Heavy Duty Washdown Pump - 12V

Jabsco Hotshot HD4 Heavy Duty Washdown Pump - 12V.                      Ref: CW-Q401J-118N-3A

Years of clean decks and satisfaction in the form of robust and reliable high-flow and high-pressure diaphragm pumps. The Jabsco legacy of exceptional products continues with this updated and improved lineup of washdown pumps and kits.

HD (Heavy Duty) models include a wider diameter motor with a powder coated shell, cast aluminium endbells and lower housing to improve pressure capability and life. Standard models provide exceptional performance in an economical footprint. A plastic housing protects the motors from corrosion.

This pump kit comes with:

• 1 x Jabsco Hotshot HD4 Washdown Pump
• 2 x Port Fittings -  1/2" / 12.7mm Straight Hosebarb
• 2 x Port Fittings - 3/4" / 19mm Straight Hosebarb
• 1 x Port Fittings - 3/4" / 19mm US GHT
• 1 x Strainer 90 Degree Quick Connect (20 Mesh)
• 1 x Standard Trigger Nozzle
• 1 x Trigger Adaptors - 1/2" (12.5mm) Crimp Style Quick Connect
• 1x  Trigger Adaptors - 3/4" (19mm) US GHT Quick Connect

Key Features:

• HD models feature heavy duty, motors and cast aluminium lower housings which allow for long-life, even at high pressures
• Efficient and quiet operation
• Integrated, sealed pressure switch for on-demand operation
• Self-priming allows for installation versatility
• Can run dry without damage
• Quick connect ports for ease of installation, servicing, and maintenance
• Vibration dampening mounting feet

Specifications:

• Motor Design: Brushed, permanent magnet TENV
• Pumphead Upper Housing Material: Glass fiber reinforced polypropylene
• Diaphragm: Co-molded TPV
• Check valves: EPDM
• Max inlet pressure: 30 PSI (2.1 Bar)
• Fluid temperature range: 32°F – 140°F (0°C – 60°C)
• Dry self-priming capability: 7ft min (2.1m min)
• Certifications: CE, ISO8846, RCM
• Ingress protection: IPX6
• Voltage VDC: 12
• Open Flow GPM (LPM): 3 (11)
• Shut-off Pressure PSI (BAR): 50 (3.4)
• Max Current AMPS: 7.5
• Recommended Fuse Size: 15
• Port Fittings: 2 x 1/2" Straight Hosebarb
• Strainer Included: Inline
• Trigger Nozzle: Standard

Dimensions:

• Overall Length in. (mm): 9.4 (239)
• Overall Width in. (mm): 4.1 (104)
• Overall Heigh in. (mm): 3.8 (97)
• Motor Height in. (mm): 3.5 (89)
• Mounting Length (ctr to ctr*) in. (mm): 2.0 (51)
• Mounting Width (ctr to ctr*) in. (mm): 3.6 (91)

For detailed dimensions, see second picture.
