Jabsco HotShot HD6 Heavy Duty Washdown Pump
Jabsco HotShot HD6 Heavy Duty Washdown Pump
SKU: CW-P601J-219N-3A
Delivery available | lead times vary
Collection available | usually ready in 2-4 days
Description
Description
This HotShot HD6 heavy duty model features a wide diameter motor (compared to standard non-HD models) with a powder-coated shell, cast aluminium endbells and lower housing to improve pressure capability and life.
The pump has vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. It has a dry self-priming capability of 2.1 meters (7ft) and can run dry without damage.
The Jabsco Xylem HotShot HD6 is supplied with quick connect straight hose barb and GHT fittings, a 90° 20 mesh quick connect strainer and trigger nozzle and quick connect hose adapters.
| Approvals | ISO 8846 Ignition Protected, C.E Certified, RCM compliant | ISO 8846 Ignition Protected, C.E Certified, RCM compliant |
| Cut In Pressure | 50 PSI | 51 PSI |
| Cut Out Pressure Description | 70 PSI / 4.8 Bar | 70 PSI / 4.8 Bar |
| Flow Rate Description | 23 LPM (6 US GPM) | 23 LPM (6 US GPM) |
| Fuse | 25A (not included) | 15A (not included) |
| Height Description | 119mm | 119mm |
| Size | Leads: 12" (305mm), 14 AWG (2.5mm^2) | Leads: 12" (305mm), 14 AWG (2.5mm^2) |
| Supplied With | Inline Strainer (40 mesh) & Quick Connect Fittings - no hosecoil | Inline Strainer (40 mesh) & Quick Connect Fittings - no hosecoil |
| Temperature Range | Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F) | Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F) |
| Voltage Description | 12V DC | 24V DC |
| Weight | 8.06kg | 8.06kg |
| Width | 129mm | 129mm |
| Brand | Jabsco | Jabsco |
| IP Rating | IPX6 | IPX6 |
| Model | P601J-219N-3A | P602J-219N-3A |
| Pressure Rating | Operating: 70 PSI (3.4 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum | Operating: 70 PSI (3.4 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum |
| Replaces | JAB-82605-0092 | JAB-82605-0094 |
| Self Primes up to | Up to 7ft (2.1m) dry prime | Up to 7ft (2.1m) dry prime |
| Inlet Outlet | Fittings for 19mm (1/2") ID hose and US Garden Hose Thread | Fittings for 13mm (1/2") ID hose and US Garden Hose Thread |
| Amps Description | 19 Amps at 70 PSI (4.8 BAR) | 9 Amps at 70 PSI (4.8 BAR) |
| Depth | 260mm | 260mm |
