Nuova Rade Complete Polyethylene Table Set - Adjustable

The Nuova Rade Complete Adjustable Polyethylene Table Set is a configurable marine table system with a round or rectangular white polyethylene top, a telescopic 60mm pedestal and a choice of flushmount or deck-mount bottom plate.

Each selected variant combines compatible Nuova Rade components for a cockpit, deck or cabin table installation. The polyethylene tops use the manufacturer's direct-to-top pedestal fixing, so a separate top plate is not required. Choose either the 380–600mm or 480–810mm telescopic pedestal; both use a quarter-turn locking action.

Product Identification

• Brand: Nuova Rade
• Product category: Complete adjustable marine table and pedestal set
• Table-top material: White polyethylene
• Table-top part numbers: 47087 round or 49722 rectangular
• Top plate: Not required; the pedestal screws directly to the polyethylene table top
• Pedestal part numbers: 44060 or 44058
• Bottom-plate part numbers: 43261 flushmount or 196163 deck-mount
• Pedestal construction: Telescopic white enamelled aluminium pedestal, 60mm diameter, with quarter-turn height locking
• Colour: White
• Set quantity: One selected table top, one selected pedestal and one selected bottom plate

What Is the Nuova Rade Complete Adjustable Polyethylene Table Set Used For?

This set is used to create a complete onboard table for dining, drinks, chart work or general use where the deck structure and available space are suitable. It is intended for marine cockpit, deck, saloon or cabin installations using the listed compatible Nuova Rade components.

What Is Included?

The exact components supplied depend on the options selected on the product page. One complete selected set contains:

• 1 x selected polyethylene table top: 47087 round or 49722 rectangular
• 1 x selected telescopic pedestal: 44060 or 44058
• 1 x selected bottom plate: 43261 flushmount or 196163 deck-mount

What Is Not Included?

Not included unless expressly stated:

• A separate table top plate; it is not required for these polyethylene tops
• Deck fasteners, backing plates, washers or structural reinforcement
• Marine sealant or bedding compound
• Installation tools
• Seating, cushions or other cockpit furniture
• A fixed-height pedestal; choose the separate fixed table-set listing where a non-adjustable installation is required.

Which Table Top Options Are Available?

• Round polyethylene top 47087: Ø600 x 30mm, white polyethylene.
• Rectangular polyethylene top 49722: 700 x 500 x 30mm, white polyethylene.

Choose the round option for a compact circular footprint or the rectangular option for a 700 x 500mm working surface. Confirm the full footprint, seating positions and access around the table before ordering.

Does the Polyethylene Table Top Require a Top Plate?

No. The Nuova Rade compatibility chart marks top plate 43263 as not applicable to polyethylene table tops 47087 and 49722. The chart states that compatible pedestals screw directly to these table tops.

Which Pedestal Size Should I Choose?

• Part 44060: telescopic pedestal with H1 range 300–520mm and H2 overall range 380–600mm.
• Part 44058: telescopic pedestal with H1 range 400–730mm and H2 overall range 480–810mm.

Use the manufacturer H2 dimension as the published overall pedestal measurement. Do not select a pedestal from the option label alone; check the intended finished height, table clearance and the complete component arrangement before drilling.

Which Bottom Plate Should I Choose?

• Flushmount 43261: white PA plate, 190mm diameter, with a published height of 10mm above the deck surface.
• Deck-mount 196163: white PA raised plate measuring Ø190 x 55mm high.

Choose the base according to deck construction, available underside access, required profile and how permanently the table will be installed. Both listed bases are shown as compatible with polyethylene tops 47087/49722 and the listed pedestals in the Nuova Rade compatibility chart.

How Do I Select the Correct Variant?

• Choose the table-top shape: round 47087 or rectangular 49722.
• Choose the pedestal option: 44060 or 44058.
• Choose the bottom-plate style: flushmount 43261 or deck-mount 196163.
• Confirm the selected components against the Nuova Rade compatibility chart.
• Measure the installation area and check the complete table-top footprint before ordering.

How Should the Table Set Be Measured Before Installation?

Select a pedestal range that contains the required installed height, then confirm the complete assembly against the Nuova Rade compatibility diagram. H1 and H2 are manufacturer pedestal dimensions; the selected table top and bottom plate also affect the final installation geometry.

• Measure the intended installation position rather than relying on an existing table size.
• Allow for the complete round or rectangular table-top footprint and safe movement around it.
• Check deck thickness, underside access and the location of wiring, hoses, tanks and structural members before drilling.
• Dry-position the components and confirm the top is level and clear of surrounding fittings.

Installation and Safety

A table pedestal transfers leverage into the deck and mounting points. Installation should be completed on a sound structure using fasteners, backing and sealant appropriate to the vessel and deck material.

• Confirm every selected part number before installation.
• Fit the compatible pedestal directly to the fixing arrangement on the polyethylene table top; do not add top plate 43263.
• Do not drill until the deck area has been checked from above and below.
• Use corrosion-resistant marine fasteners of the correct size; fasteners are not specified or supplied in this listing.
• Bed deck penetrations with a suitable marine sealant to protect the substrate from water ingress.
• Tighten PA components evenly and do not overtighten them.
• Set the telescopic pedestal to the required height and fully engage the quarter-turn lock before loading the table.
• Check that the table is level, stable and clear of controls, walkways and emergency access routes before use.
• Do not use the table or pedestal as a handhold, seat, step or lifting point.

Maintenance

• Wash the table top, pedestal and plates with fresh water and a mild cleaner suitable for the materials.
• Inspect fasteners, deck sealing and component connections periodically.
• Check the pedestal and plate interfaces for looseness, cracking, distortion or corrosion.
• Re-bed or repair any deck fixing that shows water ingress or movement.
• Replace damaged components rather than continuing to use an unstable table assembly.

Key Features

• Complete selectable Nuova Rade marine table system
• Round or rectangular white polyethylene table-top option
• Direct pedestal-to-table-top connection with no separate top plate
• Choice of 380–600mm or 480–810mm telescopic pedestal range
• 60mm white enamelled aluminium pedestal tube with PA components
• Choice of flushmount or raised deck-mount bottom plate
• Component compatibility documented by Nuova Rade

Frequently Asked Questions

Is this supplied as a complete table set? Yes. The selected variant includes one polyethylene top, one selected pedestal and one selected bottom plate. Installation fasteners and sealant are not included unless expressly stated.

Do I need to buy top plate 43263? No. Nuova Rade shows top plate 43263 as not applicable to polyethylene tops 47087 and 49722; the pedestal screws directly to the table top.

What is the difference between the flushmount and deck-mount bases? Part 43261 is a low-profile 190mm flushmount plate with a published 10mm height above deck. Part 196163 is a raised Ø190 x 55mm deck-mount plate.

How are the telescopic pedestal heights adjusted? The telescopic pedestals use a quarter-turn locking action. Part 44060 adjusts over an H2 range of 380–600mm and part 44058 over 480–810mm.

Are the round and rectangular tops the same size? No. The round top is Ø600 x 30mm. The rectangular top is 700 x 500 x 30mm.

Are mounting screws included? The listing does not specify deck fasteners. Select fasteners, backing and sealant for the vessel structure and installation method.
