Rule 27DA Non-Automatic Submersible Bilge Pump - 1100 GPH 24v

Rule 1100 Bilge Pump -1100 GPH 24V.  Ref17:  CW-27DA-24

• Connections: For 25mm (1") and 28mm (1 1/8") bore hose.
• Dimensions: 111mm high, 64mm x 74mm.
• Current Draw: 1.9(amps)
• Fuse Size: 3 amp
• Output: Up to 69 litres/minute (15 gallons/minute) without check valve. Max recommended discharge head 2m.
• Compact pump for smaller vessels.
• Tough plastic body.
• Quick release inlet strainer allows rapid cleaning.
• Low amp draw conserves batteries.
• Built-in Thermal Cut-Off. Motor rated for 1500-hour life.
• Check Valve included for Back Flow Prevention.
• Vented body to prevent air locking.
• Threaded port for easier installation and maintenance.
• For automatic operation use Rule Float Switches.
• Base not interchangeable with old range but can be fitted to existing screw holes.
• Packaged Dimensions: L:18.00 x H:9.00 x W:17.00cm
• Actual Weight: 0.41 Kg (Approx. 0.61 Kg packed)
