Whale WU7207 Inline Water Pressure Switch
Whale WU7207 Inline Water Pressure Switch
SKU: MA-WU7207B
The Whale WU7207 is an adjustable inline water pressure switch for automatic freshwater pump systems in boats, caravans and motorhomes. It senses pressure changes when a tap or shower is opened or closed, automatically switching a compatible 12V or 24V pump on or off. This is the Whale OEM version and is supplied without a retail box.
Delivery available | lead times vary
Collection available | usually ready in 2-4 days | Location: M70
Description
Description
The Whale WU7207 is an adjustable inline water pressure switch for automatic freshwater pump systems in boats, caravans and motorhomes. It senses pressure changes when a tap or shower is opened or closed, automatically switching a compatible 12V or 24V pump on or off. This is the Whale OEM version and is supplied without a retail box.
What is the Whale WU7207 used for?
The Whale WU7207 converts a simple freshwater pump installation into a pressurised water system. One pressure switch can control a multi-outlet system, allowing taps and showers to operate without a separate switch at each outlet.
How does the pressure switch work?
The switch monitors pressure within the water system. Opening a tap or shower reduces system pressure and activates the pump. Closing the outlet restores pressure and switches the pump off. The cut-in and cut-out pressure can be adjusted to suit the installation.
Which pumps are compatible?
The WU7207 is suitable for use with Whale 12V and 24V submersible pumps and self-venting inline electric pumps. It can also be used with Whale Elegance, Elite and TB taps or faucets.
What connections does it use?
- 12mm Whale Quick Connect push-fit fittings
- 13mm inside-diameter flexible hose
- Straight inline installation
Electrical Ratings
- 12V DC systems: maximum current rating of 10A
- 24V DC systems: maximum current rating of 5A
- Maximum system pressure: 2 bar / 30 psi
Construction
- Body: acetal plastic
- Seals and valves: Nitrile and EPDM
- Spring: phosphor bronze
- Fasteners: stainless steel
Installation Requirements
The pressure switch must be installed in a vertical position. An inline pump strainer is recommended upstream of the switch to prevent debris from entering the mechanism and causing damage.
Key Features
- Automatically switches the freshwater pump on and off
- Detects pressure changes caused by opening or closing an outlet
- Adjustable cut-in and cut-out pressure
- Controls multi-outlet freshwater systems
- Suitable for boats, caravans and motorhomes
- Compatible with 12V and 24V pump installations
- Maximum pressure rating of 2 bar / 30 psi
- Straight inline design
- Fits 12mm Whale pipe systems
- Suitable for 13mm inside-diameter hose
- Must be mounted vertically
- Whale OEM version
- Supplied without a retail box
| Specification | Value |
|---|---|
| Brand | Whale |
| Product Type | Inline water pressure switch |
| Application | Pressurised freshwater pump systems |
| Suitable Installations | Boats, caravans and motorhomes |
| Operating Function | Switches pump on and off by sensing system pressure changes |
| Pressure Adjustment | Adjustable cut-in and cut-out pressure |
| Maximum Pressure | 2 bar / 30 psi |
| System Voltage | 12V or 24V DC |
| Current Rating at 12V DC | 10A maximum |
| Current Rating at 24V DC | 5A maximum |
| Compatible Pumps | Whale submersible and self-venting inline electric pumps |
| Compatible Outlets | Whale Elegance, Elite and TB taps or faucets |
| System Configuration | Single or multi-outlet freshwater systems |
| Fitting Type | Push-fit stem connection |
| Pipe Compatibility | 12mm Whale Quick Connect pipe system |
| Hose Compatibility | 13mm inside-diameter hose |
| Connection Angle | Straight |
| Mounting Position | Vertical only |
| Primary Construction | Plastic |
| Body Material | Acetal |
| Seal and Valve Materials | Nitrile and EPDM |
| Spring Material | Phosphor bronze |
| Fastener Material | Stainless steel |
| Recommended Protection | Inline pump strainer |
Specification
Specification
| Specification | Value |
|---|---|
| Brand | Whale |
| Product Type | Inline water pressure switch |
| Application | Pressurised freshwater pump systems |
| Suitable Installations | Boats, caravans and motorhomes |
| Operating Function | Switches pump on and off by sensing system pressure changes |
| Pressure Adjustment | Adjustable cut-in and cut-out pressure |
| Maximum Pressure | 2 bar / 30 psi |
| System Voltage | 12V or 24V DC |
| Current Rating at 12V DC | 10A maximum |
| Current Rating at 24V DC | 5A maximum |
| Compatible Pumps | Whale submersible and self-venting inline electric pumps |
| Compatible Outlets | Whale Elegance, Elite and TB taps or faucets |
| System Configuration | Single or multi-outlet freshwater systems |
| Fitting Type | Push-fit stem connection |
| Pipe Compatibility | 12mm Whale Quick Connect pipe system |
| Hose Compatibility | 13mm inside-diameter hose |
| Connection Angle | Straight |
| Mounting Position | Vertical only |
| Primary Construction | Plastic |
| Body Material | Acetal |
| Seal and Valve Materials | Nitrile and EPDM |
| Spring Material | Phosphor bronze |
| Fastener Material | Stainless steel |
| Recommended Protection | Inline pump strainer |
